Motorola MC9500-K - Part of the MC9500-K

1 - 2 MC9500-K Mobile Computer User Guide
Part of the MC9500-K
Figure 1-1 MC9500-K
Scan
Button
Modular Keypad
(Alpha Primary
Keypad Shown)
Power Button
Volume
Up/Down Button
Touch Screen with
Protective Overlay
Microphone
Function Keys
Battery
Camera Flash (Optional)
Exit Window
Headset Connector
Speaker
Interface Connector
Scan Button
Camera (Optional)
Programmable Button
IrDA Window
Battery Release
Latch
Stylus
Interface Pocket
Battery Release
Latch
Interface Plate
Handstrap
