Motorola MTR3000 User Manual

3-64 Power Amplifier Parts List (UHF) – CLE6219
Q6591 4813972M07 PB-FREE,NOT
COMPLETELY ENRICHED
Q6593 4813972M07 PB-FREE,NOT
COMPLETELY ENRICHED
R6052 0613952A01 CER CHIP RES 1.00Ω 1%
0603
R6053 0613952A01 CER CHIP RES 1.00Ω 1%
0603
R6062 0613952A01 CER CHIP RES 1.00Ω 1%
0603
R6063 0613952A01 CER CHIP RES 1.00Ω 1%
0603
R6120 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6121 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6123 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6124 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6125 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6126 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6131 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6134 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6135 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6137 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6156 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6157 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6158 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6159 0613952D01 CER CHIP RES 1000Ω 1%
0603
Circuit
Ref
Motorola Part
No
Description
R6174 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6180 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6181 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6182 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6183 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6184 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6185 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6186 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6187 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6188 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6189 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6191 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R6210 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6211 0613952C68 CER CHIP RES 499Ω 1%
0603
R6212 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6213 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6220 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6221 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6222 0613952D34 CER CHIP RES 2210Ω 1%
0603
R6223 0613952D73 CER CHIP RES 5620Ω 1%
0603
Circuit
Ref
Motorola Part
No
Description
R6224 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6225 0613952D73 CER CHIP RES 5620Ω 1%
0603
R6226 0613952D73 CER CHIP RES 5620Ω 1%
0603
R6228 0613952D34 CER CHIP RES 2210Ω 1%
0603
R6229 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6230 0613952D18 CER CHIP RES 1500Ω 1%
0603
R6231 0613952D18 CER CHIP RES 1500Ω 1%
0603
R6232 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6233 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6235 0613952D18 CER CHIP RES 1500Ω 1%
0603
R6236 0613952D18 CER CHIP RES 1500Ω 1%
0603
R6237 0613952E66 CER CHIP RES 47.5KΩ 1
0603
R6238 0613952D91 CER CHIP RES 8660Ω 1%
0603
R6239 0613952D34 CER CHIP RES 2210Ω 1%
0603
R6243 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6244 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6261 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6263 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6280 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6281 0613952D34 CER CHIP RES 2210Ω 1%
0603
Circuit
Ref
Motorola Part
No
Description
R6282 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6283 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6284 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6285 0613952D91 CER CHIP RES 8660Ω 1%
0603
R6286 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6288 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6289 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6500 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6501 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6502 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6503 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6504 0613952D34 CER CHIP RES 2210Ω 1%
0603
R6512 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6513 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6515 0613952D73 CER CHIP RES 5620Ω 1%
0603
R6516 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6518 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6550 0613952F01 CER CHIP RES 100KΩ 1%
0603
R6551 0613952E66 CER CHIP RES 47.5KΩ
1% 0603
R6552 0613952E33 CER CHIP RES 21.5KΩ
1% 0603
Circuit
Ref
Motorola Part
No
Description
