Motorola MTR3000 User Manual

Power Amplifier Parts List (UHF) – CLE6219 3-65
R6555 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6556 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6557 0613952E66 CER CHIP RES 47.5KΩ
1% 0603
R6558 0613952D81 CER CHIP RES 6810Ω 1%
0603
R6560 0613952D73 CER CHIP RES 5620Ω 1%
0603
R6579 0613952F01 CER CHIP RES 100KΩ 1%
0603
R6580 0613952D18 CER CHIP RES 1500Ω 1%
0603
R6581 0613952D34 CER CHIP RES 2210Ω 1%
0603
R6582 0613952F01 CER CHIP RES 100KΩ 1%
0603
R6583 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6585 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6586 0613952D01 CER CHIP RES 1000Ω 1%
0603
R6587 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R6588 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R6589 0613952D73 CER CHIP RES 5620Ω 1%
0603
R6596 0613959Y15 CER CHIP RESΩ 5% 2512
R6597 0613959Y15 CER CHIP RESΩ 5% 2512
R6598 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6599 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R6701 0613952E33 CER CHIP RES 21.5KΩ
1% 0603
R6702 0613952E66 CER CHIP RES 47.5KΩ
1% 0603
Circuit
Ref
Motorola Part
No
Description
R6704 0613952C68 CER CHIP RES 499Ω 1%
0603
R6751 0613952E33 CER CHIP RES 21.5KΩ
1% 0603
R6752 0613952E66 CER CHIP RES 47.5KΩ
1% 0603
R6754 0613952D01 CER CHIP RES 1000Ω 1%
0603
RT6553 0685191Y01 THERMISTOR CHIP 100
KΩ W18
U6050 5114014A30 IC,LNR V
REGLTR,FXD,3.3V,800MA
,SM,DPAK,PB-FREE
U6060 5114014A21 IC,LNR V
REGLTR,FXD,5V,800MA,S
M,DPAK,PB-FREE
U6130 5184943Y01 64KB SERIAL EEPROM
8192X8
U6150 5185130Y02 CPLD EPM3064ATI44
W18 CMPLNT
U6170 51009279001 DAC, 8 BIT, 2 CH,
PARALLEL
U6240 51009278001 ADC, 8 BIT, 10 CH, SPI
U6400 5114016A02 IC,OP AMP,4PER
PKG,GP,SM,SO-14,PB-
FREE
U6410 5114016A02 IC,OP AMP,4PER
PKG,GP,SM,SO-14,PB-
FREE
VR6107 4813977M16 DIODE,ZEN,MBZ5237,SM,
SOT-
23,8.2V,10MA,.225W,ZEN,
PB-FREE
Circuit
Ref
Motorola Part
No
Description
