Motorola MTR3000 User Manual

Exciter Parts List (UHF) – CTE4003 7-33
C4715 2113944A52 CAP CER CHP 1000.0 PF
50V 5%
C4716 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4717 2113945C02 CAP CER CHP 10,000PF
50V 10%
C4718 2113945C02 CAP CER CHP 10,000PF
50V 10%
C4719 2113951C35 CAP,FXD,11PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4800 2113945D04 CAP CER CHP 100,000PF
25V 10%
C4801 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4802 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4803 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4804 2113944A45 CAP CER CHP 270.0 PF
50V 5%
C4805 2113944A45 CAP CER CHP 270.0 PF
50V 5%
C4807 2113944C19 CAP CER CHP 3.6PF 50V
+/- 0.25PF
C4808 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C4809 2113944C25 CAP CER CHP 6.2PF 50V
+/- 0.5PF
C4811 2113944A45 CAP CER CHP 270.0 PF
50V 5%
CR4602 4815072H01 DIODE VARACTOR
CR4603 4815072H01 DIODE VARACTOR
CR4604 4815072H01 DIODE VARACTOR
CR4605 4815072H01 DIODE VARACTOR
E4000 2485410Y01 MIN CHIP FERRITE BEAD
E4100 2485449Y01 SURFACE MOUNT
FERRITE BEAD W18
Circuit
Ref
Motorola Part
No
Description
E4300 2485410Y04 MIN CHIP FERRITE BEAD
330ΩS W18
E4301 2485410Y04 MIN CHIP FERRITE BEAD
330ΩS W18
E4302 2485410Y04 MIN CHIP FERRITE BEAD
330ΩS W18
E4400 2485410Y01 MIN CHIP FERRITE BEAD
E4500 2485410Y01 MIN CHIP FERRITE BEAD
E4501 2485410Y01 MIN CHIP FERRITE BEAD
E4600 2485410Y01 MIN CHIP FERRITE BEAD
E4700 2485410Y01 MIN CHIP FERRITE BEAD
L4500 2414032F34 IDCTR,WW,100NH,5%,400
MA,.46Ω,CER,40
Q,950MHZ SRF,SM,PB-FR
L4600 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4601 2414032F50 IDCTR,WW,24NH,5%,500
MA,.24Ω,CER,45 Q,2GHZ
SRF,SM,PB-FREE
L4602 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4603 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4604 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4605 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4606 2414032F26 IDCTR,WW,22NH,5%,500
MA,.22Ω,CER,45
Q,2.2GHZ SRF,SM,PB-
FRE
L4607 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4608 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
Circuit
Ref
Motorola Part
No
Description
L4609 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4611 2414032F27 IDCTR,FXD,27NH,5%,500
MA,.25Ω,CER,45 Q,2GHZ
SRF,SM,0805,PB-
L4612 2414032F26 IDCTR,WW,22NH,5%,500
MA,.22Ω,CER,45
Q,2.2GHZ SRF,SM,PB-
FRE
L4613 2414032F50 IDCTR,WW,24NH,5%,500
MA,.24Ω,CER,45 Q,2GHZ
SRF,SM,PB-FREE
L4614 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4615 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4700 2414032F59 IDCTR,WW,390NH,5%,290
MA,1.5Ω,CER,48
Q,560MHZ SRF,SM,PB-FR
L4701 2416540H35 CHIP INDUCTOR
L4702 2414015B15 IDCTR,FXD,22NH,2%,500
MA,.22Ω,CER,55
Q,2.6GHZ SRF,SM,0805,P
L4800 2414015B17 IDCTR,FXD,18NH,2%,600
MA,.2Ω,CER,50 Q,3.3GHZ
SRF,SM,0805,PB
L4801 2414015B17 IDCTR,FXD,18NH,2%,600
MA,.2Ω,CER,50 Q,3.3GHZ
SRF,SM,0805,PB
L4802 2414015B12 IDCTR,FXD,47NH,2%,500
MA,.34Ω,CER,40
Q,1.3GHZ SRF,SM,0805,P
P4200 28009146002 HEADER 2 X 15
VERTICAL
P4800 0982492W01 BNC CONN PCB
VERTICAL RECEPT
Q4100 4813973A54 XSTR,BIP GP
SS,NPN,T3904,SM,SC-
70,SMT,40V,.15W,200MA,
300MHZ,PB
Circuit
Ref
Motorola Part
No
Description
Q4300 4813973A34 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA
,PB-FREE
Q4301 4813973A34 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA
,PB-FREE
Q4302 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4303 4813973A34 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA
,PB-FREE
Q4304 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4503 4813973A54 XSTR,BIP GP
SS,NPN,T3904,SM,SC-
70,SMT,40V,.15W,200MA,
300MHZ,PB
Q4600 4885061Y01 XSTR NPN 6V 30UA
12GHZ PB-FREE
Q4601 4885061Y01 XSTR NPN 6V 30UA
12GHZ PB-FREE
Q4602 4805218N63 RF TRANS SOT 323
BFQ67W
Q4603 4813973A54 XSTR,BIP GP
SS,NPN,T3904,SM,SC-
70,SMT,40V,.15W,200MA,
300MHZ,PB
Q4604 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4605 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4606 4813973A34 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA
,PB-FREE
Q4700 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4701 4813973A54 XSTR,BIP GP
SS,NPN,T3904,SM,SC-
70,SMT,40V,.15W,200MA,
300MHZ,PB
Circuit
Ref
Motorola Part
No
Description
