7-34 Exciter Parts List (UHF) – CTE4003
Q4702 4813973A13 XSTR,GEN PURPOSE
SMALL
SIG,PNP,MMBT3906L,TO-
236,4, PB-FREE
Q4800 4813973A34 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA
,PB-FREE
Q4801 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
Q4802 4885065Y01 POWER MOSFET 1.3A,
20V PB-FREE
R4000 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4001 0613952Q86 CER CHIP RES 3600Ω 5
0402
R4002 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4003 0613952M42 CER CHIP RES 2670Ω 1%
0402
R4004 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4005 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4006 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4007 0613952N51 CER CHIP RES 33.2KΩ 1
0402
R4008 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4010 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4011 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4012 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4013 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4014 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4016 0613952K51 CER CHIP RES 33.2Ω 1%
0402
Circuit
Ref
Motorola Part
No
Description
R4017 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4018 0613952A73 CER CHIP RES 5.62Ω 1%
0603
R4100 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4101 0613952L18 CER CHIP RES 150Ω 1%
0402
R4102 0613952M42 CER CHIP RES 2670Ω 1%
0402
R4103 0613952M42 CER CHIP RES 2670Ω 1%
0402
R4104 0613952L66 CER CHIP RES 475Ω 1%
0402
R4105 0613952L66 CER CHIP RES 475Ω 1%
0402
R4106 0613952L39 CER CHIP RES 249Ω 1
0402
R4107 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4200 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4201 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4202 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4203 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4204 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4205 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4206 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4207 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4300 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4301 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
Circuit
Ref
Motorola Part
No
Description
R4302 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4303 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4304 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4305 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4306 0613952L44 CER CHIP RES 280Ω 1
0402
R4307 0613952L89 CER CHIP RES 825Ω 1%
0402
R4308 0613952K01 CER CHIP RES 10.0Ω 1%
0402
R4310 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4311 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4312 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4313 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4314 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4315 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4316 0613952Q59 CER CHIP RES 270Ω 5
0402
R4317 0613952M36 CER CHIP RES 2320Ω 1
0402
R4318 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4319 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4320 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4321 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4322 0613952Q59 CER CHIP RES 270Ω 5
0402
Circuit
Ref
Motorola Part
No
Description
R4323 0613952Q64 CER CHIP RES 430Ω 5
0402
R4324 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4325 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4326 0613952L44 CER CHIP RES 280Ω 1
0402
R4327 0613952C51 CER CHIP RES 332Ω 1%
0603
R4328 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4329 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4330 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4331 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4400 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4401 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4402 0613952M01 CER CHIP RES 1000Ω 1%
0402
R4403 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4404 0613952M01 CER CHIP RES 1000Ω 1%
0402
R4405 0613952M01 CER CHIP RES 1000Ω 1%
0402
R4406 0613952M01 CER CHIP RES 1000Ω 1%
0402
R4407 0613952M01 CER CHIP RES 1000Ω 1%
0402
R4408 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4409 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4410 0613952N01 CER CHIP RES 10.0KΩ 1
0402
Circuit
Ref
Motorola Part
No
Description
