Exciter Parts List (UHF) – CTE4003 7-35
R4411 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4412 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4413 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4414 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4415 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4416 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4417 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4418 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4419 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4420 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4421 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4422 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4423 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4424 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4425 0613952K68 CER CHIP RES 49.9Ω 1%
0402
R4426 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4427 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4428 0613952K51 CER CHIP RES 33.2Ω 1%
0402
R4430 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4431 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
Circuit
Ref
Motorola Part
No
Description
R4432 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4433 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4434 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4505 0613952L01 CER CHIP RES 100Ω 1%
0402
R4506 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4507 0613952L42 CER CHIP RES 267Ω 1%
0402
R4508 0613952K01 CER CHIP RES 10.0Ω 1%
0402
R4509 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4510 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4511 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4512 0613952N01 CER CHIP RES 10.0KΩ 1
0402
R4516 0613952C18 CER CHIP RES 150Ω 1%
0603
R4517 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4518 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4519 0613952C72 CER CHIP RES 549Ω 1
0603
R4520 0613952C67 CER CHIP RES 487Ω 1
0603
R4521 0613952B69 CER CHIP RES 51.1Ω 1%
0603
R4522 0613952C09 CER CHIP RES 121Ω 1%
0603
R4523 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4524 0613952N51 CER CHIP RES 33.2KΩ 1
0402
Circuit
Ref
Motorola Part
No
Description
R4525 0613952M89 CER CHIP RES 8250Ω 1%
0402
R4600 0613952B01 CER CHIP RES 10.0Ω 1%
0603
R4601 0613952B46 CER CHIP RES 29.4Ω 1%
0603
R4602 0613958C47 CER CHIP RES 301Ω 1%
0805
R4603 0613958C01 CER CHIP RES 100Ω 1%
0805
R4604 0613952D20 CER CHIP RES 1580Ω 1
0603
R4605 0613952D01 CER CHIP RES 1000Ω 1%
0603
R4606 0613952B50 CER CHIP RES 32.4Ω 1%
0603
R4607 0613952C26 CER CHIP RES 182Ω 1%
0603
R4608 0613952C26 CER CHIP RES 182Ω 1%
0603
R4609 0613952B01 CER CHIP RES 10.0Ω 1%
0603
R4610 0613952B42 CER CHIP RES 26.7Ω 1%
0603
R4611 0613958C47 CER CHIP RES 301Ω 1%
0805
R4612 0613958C01 CER CHIP RES 100Ω 1%
0805
R4613 0613952D20 CER CHIP RES 1580Ω 1
0603
R4614 0613952D01 CER CHIP RES 1000Ω 1%
0603
R4615 0613952B37 CER CHIP RES 23.7Ω 1%
0603
R4616 0613952C34 CER CHIP RES 221Ω 1%
0603
R4617 0613952C34 CER CHIP RES 221Ω 1%
0603
R4619 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
Circuit
Ref
Motorola Part
No
Description
R4621 0613952D51 CER CHIP RES 3320Ω 1%
0603
R4622 0613952D30 CER CHIP RES 2000Ω 1%
0603
R4623 0613952C30 CER CHIP RES 200Ω 1%
0603
R4624 0613958C01 CER CHIP RES 100Ω 1%
0805
R4625 0613958C47 CER CHIP RES 301Ω 1%
0805
R4627 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4628 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4629 0613958B53 CER CHIP RES 34.8Ω 1%
0805
R4630 0613952L42 CER CHIP RES 267Ω 1%
0402
R4631 0613952K01 CER CHIP RES 10.0Ω 1%
0402
R4634 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4635 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4636 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4700 0613952A09 CER CHIP RES 1.21Ω 1
R4701 0613952A09 CER CHIP RES 1.21Ω 1
R4702 0613952C31 CER CHIP RES 205Ω 1%
0603
R4703 0613952C18 CER CHIP RES 150Ω 1%
0603
R4705 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4708 0613952L58 CER CHIP RES 392Ω 1%
0402
R4709 0613952K01 CER CHIP RES 10.0Ω 1%
0402
R4710 0613952L58 CER CHIP RES 392Ω 1%
0402
Circuit
Ref
Motorola Part
No
Description
