3-8 Theory of Operation
switch (Q6590) to power the fan, to attempt to lower the PA temperature. This is entirely HW
controlled and does not require any SW action to occur. The SW control is only required for periodic
monitoring of fan functionality. During these diagnostic tests, SW will force the fan on for a short
period so that the fan current can be calculated in order to determine if the current is high or low
which would indicate if the fan is failing or has already failed. The fan current is determined by
measuring a voltage drop across a fixed series resistance located in the fan supply line (R6595/
R6596).
3.2.4.5 Module I/Os
For PA Supply Connector (J6001), refer to Table 3-1
For PA Signal Connector (J6000), refer to Table 3-2
V_FWD_DST (M6910) – V_Forward input from Output Board
V_REV_DST (M6911) – V_Reverse input from Output Board
Table 3-1 PA Supply Connector (J6001)
Pin Name Description Input/Output
1 14.2V +14.2 V Supply Input
2 Ground Ground NA
3 28.6V +28.6 V Supply Input
4 14.2V +14.2 V Supply Input
5 Ground Ground NA
6 28.6V +28.6V Supply Input
Table 3-2 PA Signal Connector (J6000)
Pin Name Description Input/Output
1 UNUSED Unused – No-Connect NA
2 BP_PA_ENABLE PA Enable Input
3 BP_RESET_N Reset Line Input
4 V_CONTROL V_Control analog (Not
base station/repeater
Interface)
Input/Output
5 UNUSED Unused – No-Connect NA
6 BP_PA_ADDR0 PA Address Line 0 Input
7 BP_CLK SPI Clock Input
8 BP_MOSI SPI MOSI Line Input
9 BP_MISO SPI MISO Line Output
10 BP_PA_ADDR1 PA Address Line 1 Input
