NE-4100 Series User’s Manual Serial Command Mode
9-5
OP Code Parameter Comments
Af
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 06
Ag
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 07
Ah
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 08
Ai
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 09
Aj
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 10
Ak
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 11
Al
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 12
Am
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 13
An
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 14
Ao
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 15
Ap
xxx.xxx.xxx.xxx
(e.g., 255.255.255.0)
accessible IP netmask 16
Operation Mode
OP Code Parameter Comments
OM
0: Real COM
1: TCP server
2: TCP client
3: UDP mode
operation mode
TCP Server Mode
OP Code Parameter Comments
TM 1 – 4 max. number of connections
TL 0 – 65535 local TCP port
TT 0 – 99 (minutes) TCP alive check time
TI 0 – 65535 (ms) inactivity time
TX
0: no delimiter
1: enable 1-character delimiter
2: enable 2 character delimiter
number of characters to use as delimiter
TY
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 1
TZ
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 2
TF 0 – 65535 (ms) force transmit time
