NE-4100 Series User’s Manual Serial Command Mode
9-6
Real COM Mode
OP Code Parameter Comments
RM 1 – 4 max. number of connections
RT 0 – 99 (minutes) TCP alive check time
RX
0: no delimiter
1: enable 1-character delimiter
2: enable 2 character delimiter
number of characters to use as delimiter
RY
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 1
RZ
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 2
RF 0 – 65535 (ms) force transmit time
TCP Client Mode
OP Code Parameter Comments
CM
0: startup
1: any character
TCP connect on
CA
xxx.xxx.xxx.xxx
(e.g., 192.168.1.1)
destination IP address 1
CB
xxx.xxx.xxx.xxx
(e.g., 192.168.1.1)
destination IP address 2
CC
xxx.xxx.xxx.xxx
(e.g., 192.168.1.1)
destination IP address 3
CD
xxx.xxx.xxx.xxx
(e.g., 192.168.1.1)
destination IP address 4
C1 0 – 65535 destination port 1
C2 0 – 65535 destination port 2
C3 0 – 65535 destination port 3
C4 0 – 65535 destination port 4
CT 0 – 99 (minutes) TCP alive check time
CI 0 – 65535 (ms) inactivity time
CX
0: no delimiter
1: enable 1-character delimiter
2: enable 2 character delimiter
number of characters to use as delimiter
CY
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 1
CZ
ASCII character in hex code
(i.e., “A1” for character 0xA1)
character to use for delimiter 2
CF 0 – 65535 (ms) force transmit time
UDP Mode
OP Code Parameter Comments
UL 0 – 65535 local listen port
UA
xxx.xxx.xxx.xxx
(e.g., 192.168.1.1)
destination IP address 1, begin range
