TN-5516/5518 User’s Manual Featured Functions
3-83
Where the first byte “FF” is fixed to “01”, the second and the third byte “VV-VV” is formed by
the port VLAN ID in hex, and the last byte “PP” is formed by the port number in hex. For
example,
01–00–0F–03 is the “Circuit ID” of port number 3 with port VLAN ID 15.
The “Remote ID” is to identify the relay agent itself. It can be one of the following types:
1. The IP address of the relay agent.
2. The MAC address of the relay agent.
3. The combination of IP address and MAC address of the relay agent.
4. A user-defined string.
Server IP Address
1
st
Server
Setting Description Factory Default
IP address for the
1st DHCP server
This assigns the IP address of the 1st DHCP server that
the switch tries to access.
None
2
nd
Server
Setting Description Factory Default
IP address for the
2nd DHCP server
This assigns the IP address of the 2nd DHCP server that
the switch tries to access.
None
