Example of the Hyperterminal for Windows:
The Null modem line must be connected to the CAN bridge CBM (X100), and the Computer
COM Port. The terminal program must be started with the a.m. settings.
After switching on the CAN bridge, the start screen on the terminal display looks like that shown
below, or similar.
Command R and >Enter<, will get the current parameters:
This is the contents for a reset CAN bridge; both baudrates are set to 125k. Before programming
all parameters in the CAN-Bridge must be delete.
> > > RTOS - UH < < <
Nuc=7.8-A Daemon=2.3 EdFm=2.L Vi/Vo=1.6 assign=0.9
Math=1.H Hyp=15.4-J R/W_P90=1.6 Dat1.4 Dev = 3.5
IDF=1.1 Prom=3.0 Editor 10.B Help=1.F Sh/sr=4.7-C
sh/ext=1.2x Shell=4.4-D XC 4.2-L Loader=6.5-F copy=1.H
ScAcc=1.3 User=0.8 I/O_Pack=25 DBV/rw=1.1 Nil=1.2
Extp=4.3 Setup=3.3e SysRes=15c EX=2.2-M Check=1.5
CBM-DP=1.8g Imp/CBM_S=5.8C T_IrLk=1.0 Flash_Prom=0.P
SRamDsk=1.8g
Fm=UHFM3.J LineEd-F=1.3G
RESET:
C200I : Using I/O-Base 0x800000 for cars 0ADRS_00200000 Flash_Prom
1*AMD29
F080
CPU-Type_68331 25.2 MHz Date_-------- Time:00:00:00
C200I: Using Interrupt 30 for card 0
C200I: Using Interrupt 30 for card 0
C200I: ´´CAN_SJA100´´ with 2 Nets identified
C200I: Hardware-Version=1.0.00
C200I: Firmware-Version=0.0.00
V1.3
>r
B0:4
B1:6
