SUPREMATouch
176
Installation
MSA
US
When the *.txt file generated above is transferred with help of the terminal program, the following
screen contents will be seen:
Press E and >Enter<, to write the parameters into the memory, and then check them by pressing
R and >Enter<.
The parameters have now been successfully set.
NOTE: The parameter setting of a CAN bridge for the CAN Bus B is carried out the same way as
the parameter setting for the CAN Bus A.
>B0 : 4
>IO : 0 I1:0
>IO : 80 I1 : 80
>IO : 100 I1 : 100
>IO : 614 I1 : 614
>IO : 714 I1 : 714
>IO : 21E I1 : 21E
>IO : 61E I1 : 61E
>IO : 71E I1 : 71E
>B1 : 9
>M1 : 0 :0xxxxxxxxxxxxxxxxx
e
>r
B0 : 4
IO : 0 I1:0
IO : 80 I1 : 80
IO : 100 I1 : 100
IO : 614 I1 : 614
IO : 714 I1 : 714
IO : 21e I1 : 21e
IO : 61eI1 : 61e
IO : 71e I1 : 71e
B1 : 9
M1 : 0 :0xxxxxxxxxxxxxxxxx
