Examples of Satellite applications
With one satellite and a LWL converter:
Fig. 111 System with one satellite and LWL converter
With 2 or n satellites and a LWL converters:
Fig. 112 System with multiple satellites and LWL converters
Here, only CAN A is displayed, CAN B is assembled in the same way.
l ≤
SUPREMA central SUPREMA satellite 1
CAN bridge
SUPREMA satellite 2
CAN bridge
SUPREMA satellite n
CAN bridge
CAN/Fibre Optic
converter
CAN/Fibre Optic
converter
Fibre Optic
l
≤ 2000m
CAN/Fibre Optic
converter
CAN/Fibre Optic
converter
Fibre Optic
l
≤ 2000m
CAN/Fibre Optic
converter
CAN/Fibre Optic
converter
Fibre Optic
l
≤ 2000m
