SUPREMA
294
SUPREMA Sensor Data Sheets
MSA
US
Connection
data:
Bridge current 280 mA
Maximum nominal current 350 mA
Power consumption 1.0 W typical (without cable length)
Cable type 35 -core, 80 % screened
Maximum loop resistance 36 ohms
Maximum cable length 1500 m (at 1.5 mm
2
cross section per wire
Cable diameter 6 ... 12 mm
Cross section per wire al-
lowed
1.0 ... 2.5 mm
2
Connection box II 2 G EEx e
II/PTB 00 ATEX 1063 with
cable inlet EEx e II KEMA 99
Order No.: 10062674
Wall angle bracket with con-
nection of potential equaliza-
tion
Order No.: 10048829
Constant cable length of sen-
sor
2.0 m
Conditions
for use:
Mounting Wall mounting
Explosion protection/HT Sen-
sor
II 2G EEx d IIC T3 (-40 °C ... +160 °C) – HT
Certificate/Sensor INERIS 03 ATEX 0208
EG Type Approval DMT 03 ATEX G 003 x (SUPREMA)
Air velocity 0 ... 6 m/s
Humidity 5 ... 95 % rel. humidity; noncondensing
Pressure 800 ... 1200 hPa
For further details see operation manual. (Order no.: 10052472)
