Only remove the protection cap (slowly while turning)
when you are ready to mount the measuring head!
Clean the internal side of the installation valve.
In case you don’t use a union or sleeve nut as connection point with o-ring, wind 4 to 5 layers of
Teflon band on the Hydrocal 1005 connection thread and mount it either directly into the valve or
into an additional adapter. If you use an adapter it should be mounted to the valve, before the Hy-
drocal 1005 will be mounted to the adapter. Wind 4 to 5 layers of Teflon band on the thread of the
adapter and mount it into the valve. Make sure that everything is fixed mechanically.
Turn the unit in order to get 12 o clock position.
