MTS Systems FlexTest SE Service Information

Calibrating a Force Sensor
Model 493.02 Controller Service
Calibration
141
Using a load standard • Adjust the Manual Cmd slider for 0 kN. Then zero the
load standard readout.
Using dead weights • Remove all dead weights. Then adjust the Offset control
for a Signal Value of 0 kN on the Input Signals
window.
D. Adjust the Manual Cmd slider to achieve a force standard
reading of 20% tension and record the meter reading. Repeat
this step for 40%, 60%, 80%, and 100% compression.

MTS Systems FlexTest SE Specifications

General

Brand	MTS Systems
Model	FlexTest SE
Category	Controller
Language	English
