Model 493.42 System I/O Connections
Model 493.02 Controller Service
Cabling
69
J55 Digital Outputs
Connector J55 Dig Out provides three general purpose digital outputs
that can send digital logic signals to external switches or logic devices.
• The digital output relays are rated for a maximum of 1 Amp max,
30 V DC/AC max.
• The outputs are optically isolated.
.
Cable specification The cabling information shown assumes a single cable destination
(with an overall shield). In other applications, the cable may have
more than one destination. For these applications an overall shield is
not practical and non-EMI connectors and back shells are permissible.
• 9 pin contact type D male EMI connector
• Back shell–EMI metallized plastic
• Cable–shielded twisted pairs as required (24 AWG minimum) with
drain wire(s) connected to the metallized backshell at the chassis.
J55 Connector Pin Assignments
P
IN NAME FUNCTION
1 dig out 1 digital out 1 relay contact
2 dig out 1 digital out 1 relay contact
3 dig out 2 digital out 2 relay contact
4 dig out 2 digital out 2 relay contact
5 N/C No connection
6 dig out 3 Digital out 3 relay contact
7 dig out 3 Digital out 3 relay contact
8 +24V out fused +24V
9 24V common 24V common
