MTS Systems FlexTest SE Service Information

Calibrating a Force Sensor
Model 493.02 Controller Service
Calibration
129
Abbreviated Procedure
Online Readers All procedure entries are hypertext links.
Click on any entry to jump to the corresponding page.
The following abbreviated procedure outlines a force sensor (load cell)
calibration process. More detailed calibration information is available
on the pages listed.
Task 1, “Get things ready,” on page 130
Task 2, “Turn on hydraulic pressure,” on page 132
Task 3, “Verify the conditioner polarity,” on page 133
Task 4, “Set the zero and offset,” on page 134
Task 5, “Gain/Delta K Calibration,” on page 135
Task 6, “Gain/Linearization Calibration,” on page 142
Task 7, “Millivolt/Volt Calibration,” on page 153
Task 8, “Establish the shunt calibration reference,” on page 157
Task 9, “Save the calibration,” on page 160
