Model 493.40 I/O Carrier Connections
Model 493.02 Controller Service
Cabling
47
Model 493.40 I/O Carrier Connections
The Model 493.40 I/O Carrier module can include up to four daughter
boards. Each installed daughter board is assigned a specific I/O Carrier
module front panel connector (J4–J7 I/O).
Transducer connections require that a conditioner daughter board is
installed in the I/O Carrier module. The following conditioners can be
installed:
– Model 493.25 Digital Universal Conditioner
– Model 493.47 Encoder
– Model 493.48 Acceleration Conditioner
See “Transducer Connections” on page 83 for more details.
• Valve connections require a valve driver daughter board be
installed in the I/O Carrier module. The following valve drivers
can be installed:
– Model 493.14 Valve Driver
– Model 493.15 3-Stage Valve Driver
• Analog I/O connections require an A/D or D/A daughter board be
installed in the I/O Carrier module. The following analog daughter
boards can be installed:
– Model 493.45 A/D Converter
– Model 493.46 D/A Converter
Automated Option If the MTS FlexTest SE Controller is equipped with the automated
option, it includes a PC, MTS Series 793 software and various types of
files, including a hardware interface file (.hwi) file. The .hwi file
defines each type of electronic module in the chassis (and associated
daughter boards), and maps each module location for the Series 793
software. The .hwi file and the physical locations for each type of
module and associated daughter boards must match. Also, the I/O
Carrier module address setting (on the module) must match the .hwi
file address.
