MTS Systems FlexTest SE Service Information

Transducer Connections
Model 493.02 Controller Service
Sensors
87
Sensor Cable Part Numbers
Sensor cables
without ID Module
See the System Cable/Jumper Plug 493 Package Selection drawing (PN
700-000-656) for the most current sensor cable part numbers.
C
ABLE DESCRIPTION CABLE MODULE
C
ONNECTOR
ADT 120º
300º
562348-XX
562531-XX
493.40 J4–J7
493.40 J4–J7
Extensometer 633 capacitive 516495-XX 493.40 J4–J7
Force Transducer w/PT connector
w/MS connector
w/PC
464402-XX
464406-XX
562529-XX
493.40 J4–J7
493.40 J4–J7
493.40 J4–J7
LVDT 464403-XX 493.40 J4–J7
∆P control 479276-XX 493.40 J4–J7
Pressure Control (Sensotec) 562530-XX 493.40 J4–J7
Strain w/Amphenol connector
w/PT connector
562336-XX
501200-XX
493.40 J4–J7
493.40 J4–J7
Temposonics
Temposonics II (low power conditioner)
Temposonics III
491532-XX
562532-XX
563167-XX
493.40 J4–J7
493.40 J4–J7
493.40 J4–J7
RVDT w/MS connector 512028-XX 493.40 J4–J7
