MTS Systems FlexTest SE Service Information

Model 493.02 Controller Service
Model 493.42 System I/O Connections
Cabling
58
Model 493.42 System I/O Connections
The Model 493.42 System I/O module is a dual-wide VME-based slave
board used in the MTS FlexTest SE Controller.
• Provides box-in and box-out, analog and digital I/O, E-Stop, and
HSM and HPU control.
• Contains three general purpose digital input channels and three
general purpose digital output channels.
• Interfaces the controller with a hydraulic power unit.
• Interfaces the controller with a hydraulic service manifold and
other devices.
• Provides one BNC channel for analog output signals. The output
signals are within ±10 V DC.
• Provides one BNC channel of analog input. The input signals must
be within ±10 V DC.
