MTS Systems FlexTest SE Service Information

Model 493.02 Controller Service
Model 493.42 System I/O Connections
Cabling
66
J51 Box In
Connector J51 Box In allows the MTS FlexTest SE controller to receive
clock, hydraulic, and interlock signals from another MTS FlexTest SE
controller.
.
J51 Connector Pin Assignments
P
IN NAME FUNCTION
1 +clk in +External clock input
2 hyd high in Hydraulic high input
3 reset in Interlock reset request input
4 signal return Signal return for optically isolated inputs
5 /intlk in Hydraulic interlock input
6 hyd low in Hydraulic low input
7 signal return Signal return for optically isolated inputs
8 master/slave in Master -/Slave select input
9 - clk in - External clock input
10 hyd hi return out Hydraulic high return output
11 reset return out Interlock reset return output
12 ground Signal ground
13 /intlk return out Hydraulic interlock return output
14 hyd low return out Hydraulic low return output
15 ground Signal ground
