MTS Systems FlexTest SE Service Information

Cable Part Numbers
Model 493.02 Controller Service
Cabling
45
Cable Part Numbers
System cables The following is a list of the most common cables, see the System
Cable/Jumper Plug 493 Package Selection drawing (MTS part number
700-000-656) for the most current and additional cable part numbers.
FlexTest SE Cables (part 1 of 2)
C
ABLE DESCRIPTION PART
N
UMBER
*
MODULE
C
ONNECTOR
JUMPER
P
LUG
†
Servovalve 252.xx single 397083-XX 493.40 J4–J7 N/A
Servovalve 252.xx dual 397084-XX 493.40 J4–J7 N/A
Servovalve 256.xx 3-stage
Valve
Valve LVDT
Calibration Cable Package
Y Adapter—Servovalve/Valve LVDT
(required for 256.xx or 257.xx servovalves)
554396-XX
397086-XX
100-026--213
397105-01
493.40 J4–J7
493.40 J4–J7
493.40 J3
493.40 J4–J7
N/A
N/A
Workstation Link (Ethernet cable) 519968-XX
10/100
‡
N/A
System ground (table top)
System ground (rack mount)
054023-XX
397092-XX gnd lug
N/A
Hydraulic Power Supply (HPU) (see “Hydraulic
Configurations” on page 221 for more
information)
397137-XX 493.42 J25 039-713-301
Hydraulic Service Manifold (HSM) 397015-XX 493.42 J28 N/A
Emergency Stop (E-STOP) 493.42 J29 100-007-947
Interlock (Intlk) Per System 493.42 J43 100-057-245
Auxiliary Power (Aux Pwr) Per System 493.42 J48 N/A
