Model 493.02 Controller Service
Hydraulic Configurations
221
Appendix A
Hydraulic Configurations
This section describes how to connect the Model 493.02 Chassis to a
variety of MTS hydraulic configurations.
You will use the following connectors and cables to connect the Model
493.02 Chassis to your HPU or HPS:
493 Chassis to
493.07 HPS Converter
• 15 contact type D female EMI connector at J25 of the 493.42
System I/O module in the rear panel of the Model 493.02 Chassis.
Backshell–EMI metallized plastic.
• 14 contact type CPC male connector at J1 of the 493.07 HPS
Converter chassis.
• Cable–24 AWG 10 conductor with overall foil shield, (Carol C0745
or equivalent) with drain wire connected to metallized plastic
backshell at the 493.02 chassis, and pin 14 at the 493.07 HPS
Converter chassis.
493.07 HPS Converter
to HPS
• 24 contact type CPC female connector at J25 of the 493.07 HPS
Converter chassis.
• 14 contact type MS connector at J1 of the HPS.
• Cable–18 AWG 14 conductor with overall foil shield, (Alpha 2248C
or equivalent) with drain wire connected to pin 4 of connector J25
and pin A of the pump connector.
Hydraulic pump
configurations
The following diagrams show how to connect the chassis to a
hydraulic power supply.
• Single 493 chassis with a 24 V PLC (programmable logic
controller) pump or 505 pump
• Single 493 chassis with a non-PLC pump
• Multiple 493 chassis with a non-PLC pump
• Compatible controllers controlling a pump
