Model 493.02 Controller Service
Calibrating Encoders
Calibration
162
Abbreviated Procedure
Online readers All procedure entries are hypertext links.
Click on any entry to jump to the corresponding page.
The following abbreviated procedure outlines an encoder calibration
process. More detailed calibration information is available on the pages
listed.
Task 1, “Get things ready,” on page 163
Task 2, “Create a calibration file,” on page 164
Task 4, “Turn on hydraulic pressure,” on page 165
Task 5, “Set the zero position,” on page 165
Task 6, “Save the calibration,” on page 166
