J52 Box Out
Connector J52 Box Out allows the MTS FlexTest SE controller to send
clock, hydraulic, and interlock signals to another MTS FlexTest SE
controller.
.
Jumper plug required If connector J52 Box Out is not used, you must install a jumper plug
to maintain the integrity of the interlocks. Use jumper plug 100-057-246
or jumper pins: 2-10, 3-11, 4-12, 5-13, 6-14, 7-15.
J52 Connector Pin Assignments
P
IN NAME FUNCTION
1 +clk in +External clock output
2 hyd high out Hydraulic high output
3 reset out Interlock reset request output
4 ground Signal ground
5 /intlk out Hydraulic interlock output
6 hyd low out Hydraulic low output
7 ground Signal ground
8 N/C No connection
9 - clk out - External clock output
10 hyd hi return in Hydraulic high return input
11 reset return in Interlock reset return input
12 signal return Signal return for optically isolated inputs
13 /intlk return in Hydraulic interlock return input
14 hyd low return in Hydraulic low return input
15 signal return Signal return for optically isolated inputs
