MTS Systems FlexTest SE Service Information

Model 493.02 Controller Service
Transducer Connections
Sensors
88
Sensor cables with ID
Module
See the System Cable/Jumper Plug 493 Package Selection drawing (PN
700-000-656) for the most sensor cable current part numbers.
Each sensor includes a cable with an ID module built into it. Use a
system cable to bridge the sensor cable to the rear panel of the
controller chassis.
C
ABLE DESCRIPTION ID MODULE W/CABLE
SYSTEM CABLE
1
1. -XX specifies cable length. –01 through –09 represent 10–50 ft. in 5 ft. increments. Higher
numbers represent custom cable lengths
.
M
ODULE
C
ONNECTOR
ADT 120º
300º
525435-XX
524436-XX
561258-XX
561259-XX
493.40 J4–J7
493.40 J4–J7
Extensometer 633 capacitive 525434-XX 525443-XX 493.40 J4–J7
Force Transducer w/PT connector
w/PC connector
w/MS connector
525425-XX
525426-XX
525427-XX
525442-XX
525442-XX
525442-XX
493.40 J4–J7
493.40 J4–J7
493.40 J4–J7
LVDT 525431-XX 525442-XX 493.40 J4–J7
∆P control 525432-XX 525442-XX 493.40 J4–J7
Pressure Control (Sensotec) 525433-XX 525442-XX 493.40 J4–J7
Strain w/Amphenol connector
w/PT connector
525429-XX
525430-XX
525442-XX
525442-XX
493.40 J4–J7
493.40 J4–J7
Temposonics
Temposonics II (low power conditioner)
525437-XX
525438-XX
561260-XX
525442-XX
493.40 J4–J7
493.40 J4–J7
RVDT w/MS connector 527508-XX 525442-XX 493.40 J4–J7
