MTS Systems FlexTest SE Service Information

Model 493.02 Controller Service
Model 493.07 HPU Converter
230
Disconnect all cables from the Model 493.07 HPU Converter before
removing the cover. Failure to do so could expose the operator to
dangerous voltages.
If the HPU Converter remains connected to a 120 volt HPS, this voltage will
be present. Always remove all cable before removing the cover.
Jumper
configurations
As shipped, the HPU interface on the 493.07 HPU Converter is
compatible with 458.10/.20, 490.01 (TestStar II), 493.xx, and 497.05
controllers.
The 493.07 HPU Converter may be connected to other controllers (as
shown in the following table) using a “Y” cable.
Note If the 493.02 chassis is the only device connected to the HPU, the
jumper settings do not matter.
Note The Model 493.07 HPU Converter can not be compatible with both
groups of controllers at the same time. If this functionality is
needed, use an HPS isolation box.
CAUTION
COMPATIBLE WITH JUMPERS
Model 458.05/.10/ .20/.40
Model 490.01
Model 497.05
Standard jumper setting:
E10–E13 remove
E14–E17 remove
E10–E11 install
E12–E13install
E14–E15 install
E16–E17install
Model 413.05
Model 436.11
Model 407.05
Jumper change required:
E10–E11remove
E12–E13 remove
E14–E15remove
E16–E17remove
E10–E13install
E14–E17install
