MTS Systems FlexTest SE Service Information

Model 493.42 System I/O Connections
Model 493.02 Controller Service
Cabling
63
Cable specification • 15 contact type D male EMI connector.
• Backshell–EMI metallized plastic.
• Cable–24 AWG 4 connector with braided shield, with the braid
connected to a metallized plastic backshell at the chassis and to
ground at the emergency stop station.
Jumper plug required If connector J29 is not used, you must install a jumper plug to
maintain the integrity of the interlocks. Use jumper plug 100-007-947B
or jumper pins: 3-4, 5-7, 8-13.
