Technical Manual N5 (CANopen)
10 Description of the object dictionary
2 => 02
h
0 => 0
The corresponding adjustment value is then C0A80200
h
.
2015h Current-IPv4-Subnet-Mask
Function
Contains the currently active subnet mask of the static IP address in the form of a 32-bit word.
Object description
Index 2015
h
Object name Current-IPv4-Subnet-Mask
Object Code VARIABLE
Data type UNSIGNED32
Savable no
Access read only
PDO mapping no
Allowed values
Preset value 00000000
h
Firmware version FIR-v1426
Change history
Firmware version FIR-v1450: "Object Name" entry changed from
"Current-IP-Subnet-Mask" to "Current-IPv4-Subnet-Mask".
Description
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Subnet Mask Part 2 [8]Subnet Mask Part 1 [8]
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Subnet Mask Part 4 [8]Subnet Mask Part 3 [8]
Subnet Mask Part 1 [8]
Specifies the first part of the subnet mask
Subnet Mask Part 2 [8]
Specifies the second part of the subnet mask
Subnet Mask Part 3 [8]
Specifies the third part of the subnet mask
Subnet Mask Part 4 [8]
Specifies the fourth part of the subnet mask
Example
The class C network mask 255.255.255.0 is first converted to hexadecimal format,
resulting in the following configuration value:
Version: 2.0.1 / FIR-v1650 222
