L NAPCO Security Systems
X GEM-X255 Programming Instructions
Page 55
WI1092E 10/05
EXTERNAL RELAY CONTROL
STEP 4: EVENT ID CODES: Each relay event can be assigned any of the available event IDs from the table.
Select 2-digit Event ID from Table 4 (below); enter in corresponding address locations (left and right digit).
Continued
TABLE 4
EVENT ID CODES
DATA ENTRIES OPTION
LEFT RIGHT
blank (•) blank (•)
Area 1 Arm
blank (•) 1
Area 2 Arm
blank (•) 2
Area 3 Arm
blank (•) 3
Area 4 Arm
blank (•) 4
Area 5 Arm
blank (•) 5
Area 6 Arm
blank (•) 6
Area 7 Arm
blank (•) 7
Area 8 Arm
C blank (•) Area 1 Disarm
C 1 Area 2 Disarm
C 2 Area 3 Disarm
C 3 Area 4 Disarm
C 4 Area 5 Disarm
C 5 Area 6 Disarm
C 6 Area 7 Disarm
C 7 Area 8 Disarm
blank (•) 8
Zone 1
blank (•) 9
Zone 2
blank (•) 0
Zone 3
blank (•) B
Zone 4
blank (•) C
Zone 5
blank (•) D
Zone 6
blank (•) E
Zone 7
blank (•) F
Zone 8
1 blank (•)
Zone 9
1 1
Zone 10
1 2
Zone 11
1 3
Zone 12
1 4
Zone 13
1 5
Zone 14
1 6
Zone 15
1 7
Zone 16
1 8
Zone 17
1 9
Zone 18
1 0
Zone 19
1 B
Zone 20
1 C
Zone 21
1 D
Zone 22
1 E
Zone 23
1 F
Zone 24
2 blank (•)
Zone 25
2 1
Zone 26
2 2
Zone 27
2 3
Zone 28
2 4
Zone 29
2 5
Zone 30
2 6
Zone 31
2 7
Zone 32
2 8
Zone 33
2 9
Zone 34
2 0
Zone 35
2 B
Zone 36
2 C
Zone 37
2 D
Zone 38
2 E
Zone 39
2 F
Zone 40
3 blank (•)
Zone 41
3 1
Zone 42
3 2
Zone 43
3 3
Zone 44
3 4
Zone 45
3 5
Zone 46
3 6
Zone 47
3 7
Zone 48
3 8
Zone 49
3 9
Zone 50
3 0
Zone 51
3 B
Zone 52
4 4
Zone 61
4 5
Zone 62
4 6
Zone 63
4 7
Zone 64
4 8
Zone 65
4 9
Zone 66
4 0
Zone 67
4 B
Zone 68
4 C
Zone 69
4 D
Zone 70
4 E
Zone 71
4 F
Zone 72
5 blank (•)
Zone 73
5 1
Zone 74
5 2
Zone 75
5 3
Zone 76
5 4
Zone 77
5 5
Zone 78
5 6
Zone 79
5 7
Zone 80
5 8
Zone 81
5 9
Zone 82
5 0
Zone 83
5 B
Zone 84
5 C
Zone 85
5 D
Zone 86
5 E
Zone 87
5 F
Zone 88
6 blank (•)
Zone 89
6 1
Zone 90
6 2
Zone 91
6 3
Zone 92
6 4
Zone 93
6 5
Zone 94
6 6
Zone 95
6 7
Zone 96
6 8
Area 1 Keypad Ambush
6 9
Area 1 Keypad Panic
6 0
Area 1 Keypad Fire
6 B
Area 1 Keypad Medical
6 C
Keypad Tamper
6 D
Area 1 Fail to Open
6 E
Area 1 Fail to Close
7 blank (•)
Area 2 Keypad Ambush
7 1
Area 2 Keypad Panic
7 2
Area 2 Keypad Fire
7 3
Area 2 Keypad Medical
7 5
Area 2 Fail to Open
7 6
Area 2 Fail to Close
7 8
Area 3 Keypad Ambush
7 9
Area 3 Keypad Panic
7 0
Area 3 Keypad Fire
7 B
Area 3 Keypad Medical
7 D
Area 3 Fail to Open
7 E
Area 3 Fail to Close
8 blank (•)
Area 4 Keypad Ambush
8 1
Area 4 Keypad Panic
8 2
Area 4 Keypad Fire
8 3
Area 4 Keypad Medical
8 5
Area 4 Fail to Open
8 6
Area 4 Fail to Close
8 8
Area 5 Keypad Ambush
8 9
Area 5 Keypad Panic
8 0
Area 5 Keypad Fire
8 B
Area 5 Keypad Medical
8 D
Area 5 Fail to Open
8 E
Area 5 Fail to Close
9 blank (•)
Area 6 Keypad Ambush
9 0
Area 7 Keypad Fire
9 B
Area 7 Keypad Medical
9 D
Area 7 Fail to Open
9 E
Area 7 Fail to Close
0 blank (•)
Area 8 Keypad Ambush
0 1
Area 8 Keypad Panic
0 2
Area 8 Keypad Fire
0 3
Area 8 Keypad Medical
0 5
Area 8 Fail to Open
0 6
Area 8 Fail to Close
0 8
Test Timer
0 0
Bus Fail
0 B
Guarded RAM Fail
0 C
Low Battery
0 D
AC Fail
0 E
EZM Tamper
0 F
Sensor Watch
B blank (•)
Telco Fault
B 8
Digital Dialer Test
B 9
Guard-Tour Fail
B B
Service Message
B C
Program Change
B D
RF Receiver Trouble
B E
Transmitter Tamper
B F
Transmitter Trouble
D blank (•)
Keypad Fail
D 1
EZM Fail
D 2
Quickloader Device Control
D 3
System Shutdown
D 4
Quickloader Keypad Reset
D 5
General System Alarm
D 8
Area 1 General System Alarm
D 9
Area 2 General System Alarm
D 0
Area 3 General System Alarm
D B
Area 4 General System Alarm
D C
Area 5 General System Alarm
D D
Area 6 General System Alarm
D E
Area 7 General System Alarm
D F
Area 8 General System Alarm
F blank (•)
Relay Group 1
F 1
Relay Group 2
F 2
Relay Group 3
F 3
Relay Group 4
F 4
Relay Group 5
F 5
Relay Group 6
F 6
Relay Group 7
F 7
Relay Group 8
F 8
Area 1 Entry Delay
F 9
Area 2 Entry Delay
F 0
Area 3 Entry Delay
F B
Area 4 Entry Delay
F C
Area 5 Entry Delay
F D
Area 6 Entry Delay
F E
Area 7 Entry Delay
F F
Area 8 Entry Delay
NOTE: Keypad Tamper must be enabled in
UL installations using jumper op-
tion on keypad.
3 C
Zone 53
3 D
Zone 54
3 E
Zone 55
3 F
Zone 56
4 blank (•)
Zone 57
4 1
Zone 58
4 2
Zone 59
4 3
Zone 60
9 1
Area 6 Keypad Panic
9 2
Area 6 Keypad Fire
9 3
Area 6 Keypad Medical
9 5
Area 6 Fail to Open
9 6
Area 6 Fail to Close
9 8
Area 7 Keypad Ambush
9 9
Area 7 Keypad Panic
To Next Page
