10 Time Domain (Scope) Mode
186 IDA-3106 Narda
10.3.3 Selecting the trace type / detector
The Measurement softkey is used firstly to set the sub mode. Depending on
this setting, only the associated trace types/detectors will be available under
Trace / Detector.
To select a trace type/detector:
1. Press the Measurement softkey and select a sub mode.
2. Press OK or ESC to exit from the menu.
3. Press the Trace / Detector softkey, select an item using the rotary
control knob, and press OK to set the selection.
 If you selected High Resolution Scope sub mode, the Trace/
Detector softkey is not shown. Only the detector Act is possible.
Table 35: Sub mode and available trace types / detectors
Sub mode Trace type/
detector
Function / Explanation
High Resolution
Scope
Act Value measured at the moment
(The Trace softkey is hidden)
Long-Time Scope +Peak,
RMS,
-Peak
Detector:
Maximum, average, and minimum value within
a compressed time interval
