5 The Main Menu
58 IDA-3106 Narda
5.1 Menu overview
This section describes the two menu levels of the Main menu and the
operating modes. The conditions necessary for the indicated softkey to be
displayed are shown in brackets.
5.1.1 Main menu
Level 1 Level 2
Direction Finding See Direction Finding on page 59.
Spectrum See Spectrum on page 60.
Level Meter See Level Meter on page 62.
Time Domain (Scope) See Time Domain (Scope) on page 63.
I/Q Analyzer See I/Q Analyzer on page 64.
Multi-Channel Power See Multi-Channel Power on page 65.
Level 1 Level 2
Settings Device Info
GPS Info
Network
Reset Settings
Service Menu
Sync Time with GPS
Antenna
External Device
Cable
Multi-Channel Table
Transmitter Table
Memory Data Viewer
Screenshot Viewer
Demod. Record Viewer
Time Controlled Storing
Comment
SD Card Format SD Card
Setups «Mark» Power on Setup
1)
1) Visible when Factory is not selected.
Power on Settings
Save Setup as
Recall Setup
Overwrite Setup
1)
Delete Setup
1)
Delete All Setups
Sort
To Next Page
