5 The Main Menu
64 IDA-3106 Narda
5.1.6 I/Q Analyzer
Level 1 Level 2
Display Save Screenshot
FFT Points, FFT Overlap, Goto Trigger Time
Screen Arrangement, Save Setup as
Y-Scale Range, Y-Scale Ref, Y-Scale Auto
Unit
Marker Display
Marker Settings
Delta Marker
Navigation: Time/Frequency
Active Marker: A/B
Highest Peak, Next Peak, Peak Left, Peak Right
Active Detector (Long-Time Scope selected)
View View: I/Q/Magnitude/Sgram Full/Sgram Zoom/
Persistence
Extras Select Multi-Channel Table
Select Channel
Backwards (setting parameters were changed)
Forwards (Backwards selected once)
Select Transmitter Table
Add Transmitter
Go to: ...
Level 1 Level 2
Fcent Rotary Knob: Immediate/Preselect/TxTbl
(Fcent selected, TxTbl only if Transmitter
Table selected)
Step Size: Auto/Fix
Set Fstep (Step Size: Fix selected)
Time Span Mode: s/hh:mm:ss
BW/BW (Fspan) VBW
Reference Level + 5 dB
- 5 dB
RL Search Type: Sensitive/Safe
RL Search
Preamp: On/Off
External Device: On/Off
(if an external device is defined)
Trigger Menu Display
Marker
View: I/Q/Magnitude/Sgram Full/Sgram
Zoom/Persistence
Trigger Mode
To Next Page
