10.4 Measurement parameter examples
Narda IDA-3106 187
10.4 Measurement parameter examples
Some examples of measurement parameter settings for typical applications
are given below.
10.4.1 Example 1: GSM
GSM is characterized by the following properties:
• BCCH and several traffic channels
• Channel bandwidth 200 kHz
• Cycle time: 8 timeslots of 577 s each = 4.6 ms
This results in the following settings:
Parameter Function / Setting
Fcent Center frequency of GSM channel to be observed,
e.g. 931.1879 MHz
CBW 200 kHz
Measurement High Resolution Scope
Time Span > 4.6 ms, selected: 5 ms
Time Resolution Automatically set from 1/CBW = 5 s
