17 Specifications
250 IDA-3106 Narda
17.2.3 RF input
17.2.4 General specifications
3rd order intermodulation • f 50 MHz:
< -76 dBc for two single tones with a level of 6 dB below RL,
spaced by 1 MHz or more,
IP3 +22 dBm (@ RL = -10 dBm)
• f > 50 MHz:
< -60 dBc for two single tones with a level of 6 dB below RL,
spaced by 1 MHz or more,
IP3 +14 dBm (@ RL = -10 dBm)
Spurious responses
(input related)
< -60 dBc or RL -60 dB (whichever is worse)
and a carrier offset of 100 kHz or more
Spurious responses
(residual)
1)
< -90 dBm
1) RL = -30 dBm (input attenuation = 0 dB)
Type N-Connector, 50 , female
Maximum RF power level +27 dBm (destruction limit)
Maximum DC voltage 50 V
Return loss
1)
• > 12 dB (typ.), f 4.5 GHz
• > 10 dB (typ.), f > 4.5 GHz
1) RL -28 dBm (input attenuation 2 dB)
Display • Type: TFT color display with backlight
• Size, resolution: 7 inch (152 mm x 91 mm), 800 x 480 pixels
Interface • Ethernet (100BaseT)
• USB mini B (USB 2.0)
• Optical RS232 (Baud rate 115 200)
• Earphone 3.5 mm TRS, 16 ohms (mono), switches off the
integrated speaker when connected
• microSD card interface for maps and export of measurement
data, screenshots and WAV
Antenna detection Narda Directional Antennas are automatically detected (type,
polarization, consideration of typical antenna factors, preamp gain
and frequency response).
For other antennas parameters can be defined and selected
manually.
Cables and external devices Narda RF cables are automatically detected (type, frequency
response and more)
Other cables and external devices (e.g. filters) can be defined and
selected manually.
