NetApp E Series Maintaining

Note: The HIC comes with three screw locations on the top, but is secured with only one.
Note: The image above is an example, the appearance of your HIC may differ.
6. Carefully detach the HIC from the controller card by lifting the card up and out of the
controller.
Attention: Be careful not to scratch or bump the
components on the bottom of the HIC or on the top of
the controller card.
Note: The image above is an example, the appearance of your HIC may differ.
7. Place the HIC on a flat, static-free surface.
After you finish
Go to
Upgrade host interface card .
Maintaining EF300 and EF600 Hardware
61
Host interface cards

NetApp E Series Specifications

General

Form Factor	2U, 4U
Drive Types	SSD
Host Interface	SAS, iSCSI, FC, IB
RAID Levels	RAID 0, 1, 5, 6, 10
Operating System Compatibility	Windows, Linux, VMware
Management Software	SANtricity
