NetApp E Series Maintaining

Attention: To prevent degraded performance, do not
twist, fold, pinch, or step on the cables.
4. Confirm that the Cache Active LED on the back of the controller is off.
5. Squeeze the handles on either side of the controller, and pull back until it releases from the
shelf.
6. Using two hands and the handles, slide the controller canister out of the shelf. When the front
of the controller is free of the enclosure, use two hands to pull it out completely.
Attention: Always use two hands to support the
weight of a controller canister.
7. Place the controller canister on a flat, static-free surface.
After you finish
Go to Add the new SAS expansion card .
Maintaining EF300 and EF600 Hardware
86
SAS expansion cards

NetApp E Series Specifications

General

Form Factor	2U, 4U
Drive Types	SSD
Host Interface	SAS, iSCSI, FC, IB
RAID Levels	RAID 0, 1, 5, 6, 10
Operating System Compatibility	Windows, Linux, VMware
Management Software	SANtricity
