Factory Default Settings and Specifications
167
AC1900, N900, and N450 WiFi Cable Data Gateways
Technical and Environmental Specifications
2. Maximum WiFi signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network conditions
and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower
actual data throughput rate.
Table 6. Cable data gateway specifications
Feature Description
Data and routing protocols TCP/IP, DHCP server and client, DNS relay, NAT (many-to-one), TFTP client,
VPN pass-through (IPSec, PPTP), DNS, UPnP
Power adapter AC1900 WiFi Cable Data Gateway, Model C6300BD:
• North America (input): 120V, 60 Hz, input
• North America (output): 12VDC @ 3.5A output 42W maximum
N900 WiFi Cable Data Gateway, Model CG4500BD:
• North America (input): 120V, 60 Hz, input
• North America (output): 12VDC @ 2.5A output 30W maximum
N450 WiFi Cable Data Gateway, Model CG3000Dv2:
• North America (input): 120V, 60 Hz, input
• North America (output): 12VDC @ 2.5A output 30W maximum
Dimensions and weight AC1900 WiFi Cable Data Gateway, Model C6300BD:
• 10.2 by 6.49 by 3.65 in. (259.17 by 164.77 by 92.72 mm)
• 1.52 lb (0.69 kg)
N900 WiFi Cable Data Gateway, Model CG4500BD:
• 10.2 by 6.49 by 3.65 in. (259.17 by 164.77 by 92.72 mm)
• 1.34 lb (0.61 kg)
N450 WiFi Cable Data Gateway, Model CG3000Dv2:
• 10.2 by 6.49 by 3.65 in. (259.17 by 164.77 by 92.72 mm)
• 1.30 lb (0.59 kg)
WAN port One coaxial cable connector
DOCSIS 3.0. backward compatible with DOCSIS 2.0, 1.1, and 1.0
LAN ports Four 10/100/1000BASE-T, RJ-45 autosensing ports
USB port or ports AC1900 WiFi Cable Data Gateway, Model C6300BD:
One USB 2.0 port
N900 WiFi Cable Data Gateway, Model CG4500BD:
One USB 2.0 port
N450 WiFi Cable Data Gateway, Model CG3000Dv2:
Two USB 2.0 ports
