NETGEAR DGN2200M User Manual

Internet Configuration
12
N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition
Router Label
The label on the left side of the wireless modem router shows the router’s MAC address,
serial number, security PIN, and factory default login information.
Restore Factory
Settings: Press for
6 seconds.
Router information
- Default access address
- Default user name and password
- Security PIN
- Serial number
- MAC address
Note: If the label on your router looks like the one in the following figure,
then your router has no preset wireless security. You need to set the
wireless security to protect your network.
Restore Factory
Settings: Press for
6 seconds.
Router information
- Default access address
- Default user name and password
- Security PIN
- Serial number
- MAC address

NETGEAR DGN2200M Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Security features	IDS, DoS
Dimensions (WxDxH)	173 x 128 x 33 mm
Minimum system requirements	IE 5.0+
Compatible operating systems	Windows 7 Windows Vista Windows XP Windows 2000 Mac OS
WLAN data transfer rates supported	11, 54, 150, 300 Mbit/s
DHCP client	-
Supported network protocols	TCP/IP, DNS
Antennas quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CEC, RoHS, WEEE
Cables included	Phone (RJ-11), USB
Product color	Black
LED indicators	LAN, Power, USB, WLAN, Y

Weight and Dimensions

Weight	300 g
