NETGEAR DGN2200M User Manual

USB Storage
71
N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition
Create a Network Folder
 To create a network folder:
1. From the USB Storage (Advanced Settings) screen, click the Create a Network Folder
button to open the Create a Network Folder screen:
Access Method Network
Connection
Enabled by default, this allows all users on the LAN to have access
to the USB drive.
HTTP Disabled by default. If you enable this setting, you can type
http://readyshare to access the USB drive.
HTTP (via
Internet)
Disabled by default. If you enable this setting, remote users can type
http://readyshare to access the USB drive over the Internet.
FTP Disabled by default.
FTP (via
Internet)
Disabled by default. If you enable this setting, remote users can
access the USB drive through FTP over the Internet.
Available
Network Folders
Folder Name Full path of the used by the network folder.
Volume name Volume name from the storage device (either USB drive or HDD).
Total/Free
Space
The current utilization of the storage device.
Share Name • You can click the name shown, or you can type it into the address
field of your web browser.
• If Not Shared is shown, then the default share has been deleted,
and no other share for the root folder exists. Click the link to
change this setting.
Read and Write
Access
Shows the permissions and access controls on the network folder.
• All-no password allows all users to access the network folder.
• admin prompts you to enter the same password that you use to
log in to the wireless modem router main menu.
Table 10. USB Storage (Advanced Settings) (continued)
Fields Description

NETGEAR DGN2200M Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Security features	IDS, DoS
Dimensions (WxDxH)	173 x 128 x 33 mm
Minimum system requirements	IE 5.0+
Compatible operating systems	Windows 7 Windows Vista Windows XP Windows 2000 Mac OS
WLAN data transfer rates supported	11, 54, 150, 300 Mbit/s
DHCP client	-
Supported network protocols	TCP/IP, DNS
Antennas quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CEC, RoHS, WEEE
Cables included	Phone (RJ-11), USB
Product color	Black
LED indicators	LAN, Power, USB, WLAN, Y

Weight and Dimensions

Weight	300 g
