USB Storage
74
N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition
3. The directories of the USB drive that your account has access to display, for example,
share/partition1/directory1. You can now read and copy files from the USB directory.
Connect to the USB Drive with Microsoft Network Settings
You can access the USB drive from local computers on your home or office network using
Microsoft network settings. You need to be running Microsoft Windows 2000, XP, or older
versions of Windows with Microsoft Networking enabled. You can use normal Explorer
operations such as dragging and dropping, opening files, or cutting and pasting files from:
Microsoft Windows Start menu, Run option
Windows Explorer
Network Neighborhood or My Network Place
Enable File and Printer Sharing
Each computer’s network properties need to be set to enable network communication with
the USB drive. File and Printer Sharing for Microsoft Networking needs to be enabled, as
described in the following sections.
Note: In Windows 2000 and Windows XP, File and Printer Sharing is
enabled by default.
Configure Windows 98SE and Windows ME
The easiest way to get to your network properties is to go to your desktop, right-click
Network Neighborhood, and then select Properties. File and Printer Sharing for Microsoft
Windows should be listed. If it is not, click Add, and follow the installation prompts.
Note: If you have any questions about File and Printer Sharing, contact
Microsoft for assistance.
Configure Windows 2000 and Windows XP
Right-click the network connection for your local area network. File and Printer Sharing for
Microsoft Windows should be listed. If it is not, click Install, and follow the installation
prompts.

Table of Contents

Other manuals for NETGEAR DGN2200M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR DGN2200M and is the answer not in the manual?

NETGEAR DGN2200M Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Bandwidth2.4 GHz
Security featuresIDS, DoS
Dimensions (WxDxH)173 x 128 x 33 mm
Minimum system requirementsIE 5.0+
Compatible operating systemsWindows 7 Windows Vista Windows XP Windows 2000 Mac OS
WLAN data transfer rates supported11, 54, 150, 300 Mbit/s
DHCP client-
Supported network protocolsTCP/IP, DNS
Antennas quantity2
Ethernet LAN (RJ-45) ports4
Security algorithmsWEP, WPA, WPA-PSK, WPA2, WPA2-PSK
CertificationCEC, RoHS, WEEE
Cables includedPhone (RJ-11), USB
Product colorBlack
LED indicatorsLAN, Power, USB, WLAN, Y
