NETGEAR DGN2200M User Manual

Managing Your Network
60
N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition
View Attached Devices
The Attached Devices screen contains a table of all IP devices that the wireless modem
router has discovered on the local network. In the main menu, under Maintenance, select
Attached Devices to view the table.
For each device, the table shows the IP address, device name if available, and the Ethernet
MAC address. Note that if the wireless modem router is rebooted, the table data is lost until
the wireless modem router rediscovers the devices. To force the wireless modem router to
look for attached devices, click the Refresh button.
Authentication Success or Failed.
Obtaining IP Address The IP address assigned to the WAN port by the ADSL Internet service provider.
Obtaining Network Mask The network mask assigned to the WAN port by the ADSL Internet service
provider.
Table 8. Connection Status fields (PPPoE network type example) (continued)
Field Description

NETGEAR DGN2200M Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Security features	IDS, DoS
Dimensions (WxDxH)	173 x 128 x 33 mm
Minimum system requirements	IE 5.0+
Compatible operating systems	Windows 7 Windows Vista Windows XP Windows 2000 Mac OS
WLAN data transfer rates supported	11, 54, 150, 300 Mbit/s
DHCP client	-
Supported network protocols	TCP/IP, DNS
Antennas quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CEC, RoHS, WEEE
Cables included	Phone (RJ-11), USB
Product color	Black
LED indicators	LAN, Power, USB, WLAN, Y

Weight and Dimensions

Weight	300 g
