NETGEAR DGN2200M User Manual

USB Storage
72
N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition
2. Create a folder.
• You can specify the folder’s share name read access and write access from All-no
password to
admin.
• The password for admin is the same one that is used to log in to the wireless modem
router main menu. By default it is password.
3. Click Apply so that your changes take effect.
Unmount a USB Drive
WARNING:
Unmount the USB drive first before physically unplugging it from
the wireless modem router. If the USB disk is removed or a cable
is pulled while data is being written to the disk, it could result in
file or disk corruption.
To unmount a USB disk drive so that no users can access it, from the USB Settings screen,
click the Safely Remove USB button. This takes the drive offline.
Specify Approved USB Devices
You can specify which USB devices are approved for use when connected to the router.
 To specify approved USB devices:
1. On the router main menu, under Advanced, select USB Settings.

NETGEAR DGN2200M Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Security features	IDS, DoS
Dimensions (WxDxH)	173 x 128 x 33 mm
Minimum system requirements	IE 5.0+
Compatible operating systems	Windows 7 Windows Vista Windows XP Windows 2000 Mac OS
WLAN data transfer rates supported	11, 54, 150, 300 Mbit/s
DHCP client	-
Supported network protocols	TCP/IP, DNS
Antennas quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CEC, RoHS, WEEE
Cables included	Phone (RJ-11), USB
Product color	Black
LED indicators	LAN, Power, USB, WLAN, Y

Weight and Dimensions

Weight	300 g
