NETGEAR SRX5308 User Manual

Virtual Private Networking Using IPSec Connections
159
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Figure 102.
The Active IPSec SAs table lists each active connection with the information that is described
in the following table. The default poll interval is 5 seconds. To change the poll interval period,
enter a new value in the Poll Interval field, and then click Set Interval. To stop polling, click
Stop.
View the VPN Firewall IPSec VPN Logs
 To view the IPSec VPN logs:
Select Monitoring > VPN Logs. The VPN Logs submenu tabs display, with the IPSec VPN
Logs screen in view:
Table 36. IPSec VPN Connection Status screen information
Item Description
Policy Name The name of the VPN policy that is associated with this SA.
Endpoint The IP address on the remote VPN endpoint.
Tx (KB) The amount of data that is transmitted over this SA.
Tx (Packets) The number of IP packets that are transmitted over this SA.
State The current status of the SA. Phase 1 is the authentication phase, and Phase 2 is key
exchange phase. If there is no connection, the status is IPSec SA Not Established.
Action Click the Connect table button to build the connection, or click the Disconnect table
button to terminate the connection.
