NETGEAR SRX5308 User Manual

LAN Configuration
77
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Note: The VPN firewall automatically sets up routes between VLANs and
secondary IP addresses that you have configured on the LAN
Multi-homing screen (see Configure Multi-Home LAN IP Addresses
on the Default VLAN on page 65). Therefore, you do not need to
manually add a static route between a VLAN and a secondary IP
address.
Configure Static Routes
 To add a static route to the Static Routes table:
1. Select Network Configuration > Routing. The Routing screen displays:
Figure 38.
For information about the fields of the Static Routes table, see the following table.
2. Click the Add table button under the Static Routes table. The Add Static Route screen
displays:
Figure 39.
