Monitoring System Access and Performance
291
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Use the Diagnostics Utilities
From the Diagnostics screen you can perform diagnostics that are discussed in the following
sections:
• Send a Ping Packet or Trace a Route
• Look Up a DNS Address
• Display the Routing Table
• Reboot the VPN Firewall
• Capture Packets
Note: For normal operation, diagnostics are not required.
 To view the Diagnostics screen:
Select Monitoring > Diagnostics. The Diagnostics screen displays:
Figure 178.
Send a Ping Packet or Trace a Route
Use the ping utility to perform one of the following diagnostic actions:
• Send a ping packet request to check the connection between the VPN firewall and a
specific IP address. The ping results are displayed on the Ping screen; Click Back on the
browser menu bar to return to the Diagnostics screen.
