LAN Configuration
76
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
3. Click Apply to save your settings.
Note: The DMZ LED next to LAN port 4 (see Front Panel on page 14)
lights green to indicate that the DMZ port is enabled.
For information about how to define the DMZ WAN rules and LAN DMZ rules, see Set
DMZ WAN Rules on page 96 and Set LAN DMZ Rules on page 99, respectively.
Manage Routing
Static routes provide additional routing information to your VPN firewall. Under normal
circumstances, the VPN firewall has adequate routing information after it has been
configured for Internet access, and you do not need to configure additional static routes. You
should configure static routes only for unusual cases such as multiple firewalls or multiple IP
subnets located on your network.
Enable LDAP
information
Select the Enable LDAP information check box to enable the DHCP server to
provide Lightweight Directory Access Protocol (LDAP) server information. Enter
the following settings:
LDAP Server The IP address or name of the LDAP server.
Search Base The search objects that specify the location in the directory tree
from which the LDAP search begin. You can specify multiple
search objects, separated by commas. The search objects
include:
• cn (for common name)
• ou (for organizational unit)
• o (for organization)
• c (for country)
• dc (for domain)
For example, to search the Netgear.net domain for all last
names of Johnson, you would enter:
cn=Johnson,dc=Netgear,dc=net
Port The port number for the LDAP server. The default setting is 0
(zero).
DNS Proxy
Enable DNS Proxy This is optional. Select the Enable DNS Proxy radio button to enable the VPN
firewall to provide a LAN IP address for DNS address name resolution. This setting
is enabled by default.
Table 14. DMZ Setup screen settings (continued)
Setting Description
