304
A
A. Default Settings and Technical
Specifications
You can use the Factory Defaults Reset button on the rear panel to reset all settings to their
factory defaults. This is called a hard reset (for more information, see Revert to Factory Default
Settings on page 260).
• To perform a hard reset, press and hold the Factory Defaults Reset button for
approximately 8 seconds (until the Test LED blinks rapidly). The VPN firewall returns to
the factory configuration settings that are shown in the following table.
• Pressing the Factory Defaults Reset button for a shorter period of time simply causes the
VPN firewall to reboot.
The following table shows the default configuration settings for the VPN firewall:
Table 75. VPN firewall default configuration settings
Feature Default behavior
Router login
User login URL https://192.168.1.1
Administrator user name (case-sensitive) admin
Administrator login password (case-sensitive) password
Guest user name (case-sensitive) guest
Guest login password (case-sensitive) password
Internet connection
WAN MAC address Use default address
WAN MTU size 1500
Port speed 10/100/1000 AutoSense
Local network (LAN)
LAN IP address 192.168.1.1
Subnet mask 255.255.255.0
RIP direction None
RIP version Disabled
