Monitoring System Access and Performance
290
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Group drop-down list in the Add Known PCs and Devices section or on the Edit Groups
and Hosts screen (see Figure 35 on page 71).
• Profile Name. The VLAN to which the computer or device is assigned.
• Action. The Edit table button, which provides access to the Edit Groups and Hosts
screen.
Note: If the VPN firewall is rebooted, the data in the Known PCs and
Devices table is lost until the VPN firewall rediscovers the devices.
View the DHCP Log
To review the most recent entries in the DHCP log:
1. Select Network Configuration > LAN Settings. The LAN Settings submenu tabs
display, with the LAN Setup screen in view (Figure 30 on page 59).
2. Click the DHCP Log option arrow in the upper right of the LAN Setup screen. The DHCP
Log screen displays:
Figure 177.
To view the most recent entries, click the Refresh Log button. To delete all the existing
log entries, click the Clear Log button.
